Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
Novel appearance
Adopting the latest Yuchai design language, the shape is powerful, the appearance is atmospheric, and the reflective strip design on both sides is eye-catching and improves safety.
Wider range
The detachable mast integrates the low headroom design concept, which can be adapted to a variety of height-restricted working conditions, and the construction efficiency is more efficient; the strengthened parallelogram variation function provides a larger scope of construction work, which meets the more comprehensive needs of customers.
Flexible transportation
The inverted mast can be transported on a truck without disassembling the drill pipe, and the main engine and accessories can be transported in only one truck, which saves freight costs and reduces operating costs.
Efficient construction
Dual power head motor reducer design, more stable torque output, more efficient operation efficiency, equipped with a key high-speed dumping function, soft and hard to eat; the use of large triangular body structure, high efficiency of the hole.
Environmentally friendly power
Equipped with Yuchai new generation engine, EGR+DOC+DPF control mode, no need to add urea, environmental protection and economy, strong power, high efficiency and fuel saving.
Comfortable space
The new cab has large space, reasonable layout, solid structure, air suspension seat with good shock absorption, no fatigue for long time working; one key start, convenient and reliable; automatic air conditioning, multiple air vents.
Convenient operation
The left and right pilot handles are upgraded to four-button handles common to large-tonnage drilling rigs; the guide pulley is added to the secondary winch, which makes it more convenient to use the lifting accessories; the wire rope of the main winch is wound in a single layer with a large drum, so that there is no extrusion and abrasion between the ropes, and it has a long service life.
Deeper drilling
It can be equipped with 4 sections of locking rods and friction rods, which can reach the maximum depth of the same class models.
|
Main parameter |
Units |
Parameters |
|
Chasis |
|
|
|
Engine Model |
|
YCF36125 |
|
Rated Power/Rotary Speed |
kW/rpm |
92/2200 |
|
Rotary Drive |
|
|
|
Max.output torque |
kN•m |
65 |
|
Rotary speed |
rpm |
0～35 |
|
Max.pull-down piston push |
t |
110 |
|
Max.pulling force |
t |
130 |
|
Max.pull-down piston strlke |
mm |
2000 |
|
Main winch |
|
|
|
Max.pulling force |
t |
95 |
|
Max.pulling speed |
m/min |
85 |
|
Wire Rope Diameter |
mm |
φ18 |
|
Auxiliary winch |
|
|
|
Max.pulling force |
t |
95 |
|
Max.pulling speed |
m/min |
75 |
|
Wire Rope Diameter |
mm |
φ12 |
|
Mast Rake |
|
|
|
Forwards backwards |
° |
5 |
|
Side backwards |
° |
±4 |
|
Drilling hole |
|
|
|
Max.Drilling Diameter |
mm |
600~1200 |
|
The max.drilling depth |
m |
27 |
|
Main machine |
|
|
|
Machine weight |
t |
22 |
|
Transporting state size |
mm |
11520×2600×3480 |
|
Working state size |
mm |
5300×2600×12460 |
|
Recommended drill pipe type |
|
|
|
Drill pipe configuration |
|
MZ/JS φ299-4×7.6 m |
Novel appearance
Adopting the latest Yuchai design language, the shape is powerful, the appearance is atmospheric, and the reflective strip design on both sides is eye-catching and improves safety.
Wider range
The detachable mast integrates the low headroom design concept, which can be adapted to a variety of height-restricted working conditions, and the construction efficiency is more efficient; the strengthened parallelogram variation function provides a larger scope of construction work, which meets the more comprehensive needs of customers.
Flexible transportation
The inverted mast can be transported on a truck without disassembling the drill pipe, and the main engine and accessories can be transported in only one truck, which saves freight costs and reduces operating costs.
Efficient construction
Dual power head motor reducer design, more stable torque output, more efficient operation efficiency, equipped with a key high-speed dumping function, soft and hard to eat; the use of large triangular body structure, high efficiency of the hole.
Environmentally friendly power
Equipped with Yuchai new generation engine, EGR+DOC+DPF control mode, no need to add urea, environmental protection and economy, strong power, high efficiency and fuel saving.
Comfortable space
The new cab has large space, reasonable layout, solid structure, air suspension seat with good shock absorption, no fatigue for long time working; one key start, convenient and reliable; automatic air conditioning, multiple air vents.
Convenient operation
The left and right pilot handles are upgraded to four-button handles common to large-tonnage drilling rigs; the guide pulley is added to the secondary winch, which makes it more convenient to use the lifting accessories; the wire rope of the main winch is wound in a single layer with a large drum, so that there is no extrusion and abrasion between the ropes, and it has a long service life.
Deeper drilling
It can be equipped with 4 sections of locking rods and friction rods, which can reach the maximum depth of the same class models.
