1.Highly Integrated: key components are modularized, total length 2490 mm, facilitating vehicle upgrades.
2.Powerful & Efficient: 0–9 km/h operating acceleration <5 s, torque reserve ≥40%, operating efficiency increased by 15–35%.
3.Fuel-Efficient & Eco-Friendly: hybrid-specific engine with thermal efficiency ≥49%, CO₂ emissions reduced by ≥20%.
4.Reliable & Durable: B10 life ≥30,000 hours.
5.Safe & Comfortable: automotive-grade protection, intelligent 4WD, smart differential lock, and driver-assist functions for simple and comfortable operation.
| Technical Indicators | Parameters |
| Engine Displacement (L) | 9.5 |
| Engine Rated Power (kW) | 294 |
| Voltage Platform (V) | 600 |
| Generator Power | 220 |
| Drive Motor Power | 210 |
| Transmission Type | AMT |
| Transmission Ratio | 2.26/0.79 |
| PTO Output Type | Mechanical direct drive |
| Motor Controller | Optional |
| L*W*H(mm) | 2490×790×1185 |
| Weight(kg) | 1920 |
Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
