Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
1.Multifunction
2.High-efficiency
3.Strong power
4.Low consumption
5.Easy operation
6.Simply maintenance
|
Basic parameter |
|
|
Weight |
26650kg |
|
Engine |
Cummins QSF3.8 |
|
Rated power |
124/2050kW/rpm |
|
Max diameter |
600mm |
|
Performance parameter |
|
|
Max slewing speed |
11~15 r/min |
|
Travel speet |
3.2/4.7km/h |
|
Fuel tank |
350L |
|
Hydraulic tank |
210L |
|
Gradeability |
35° |
|
Operation parameter |
|
|
Max.Operating Radius |
8577mm |
|
Man.Operating Depth |
5300mm |
|
Max.Operating Height |
8900mm |
|
Platform Tail Turning Radius |
2830mm |
|
Transportation dimension |
|
|
Length |
9465mm |
|
Width |
3000mm |
|
Height |
4080mm |
|
Other Parameter |
|
|
Lenght Of Track |
4406mm |
|
Track Gauge |
3610mm |
|
Width Of Track |
600mm |
|
Height Between |
782mm |
1.Multifunction
2.High-efficiency
3.Strong power
4.Low consumption
5.Easy operation
6.Simply maintenance
