Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
1.New generation products
2.Chinese Ill emission
3.Advanced hydraulic system
4.Durable metal covering panels
5.Safe and comfortable cab
6.Reliable and durable structural
|
Chain saw |
|
|
|
Chainsaw maximum cutting diameter |
mm |
350 |
|
Guide bar length |
mm |
457.2（18 in） |
|
Chain pitch |
mm |
0.404 |
|
Capacity of chain oil tank bar |
L |
3.4 |
|
Feeding |
|
|
|
Rollers quantity |
|
2 |
|
Rollers diameter |
mm |
371 |
|
Max. opening of rollers |
mm |
400 |
|
Max. feed force |
KN |
16 |
|
Max. feed speed |
m/s |
0~4.1 |
|
Delimbing knife |
|
|
|
Knives qty |
|
2+1 |
|
Diameter tip-to-tip |
mm |
330 |
|
Front knives max. opening |
mm |
480 |
|
Rear knives max. opening |
mm |
/ |
|
Hydraulic requirement |
|
|
|
Operating hydraulic |
MPa |
25 |
|
Flow required |
L/min |
150~180 |
|
Power required |
KW |
40~60 |
|
Operating vdtage |
V |
24 |
|
Control system |
|
YUCHAI |
|
Application |
|
|
|
For Excavator |
T |
8~15 |
|
Technical specification |
|
|
|
Width（head closed/head open） |
mm |
870/1130 |
|
Length |
mm |
1140 |
|
Height |
mm |
1100 |
|
Weight |
kg |
600 |
1.New generation products
2.Chinese Ill emission
3.Advanced hydraulic system
4.Durable metal covering panels
5.Safe and comfortable cab
6.Reliable and durable structural
