（1）600kW~1000kW prime genset, for continuous and stable power supply.
（2）660kW~1100kW standby genset, for reliable and fast standby power supply.
One head for one cylinder, with a maintenance window on the side of the engine body, which is convenient for maintenance. Support dual-energy startup.
Electric pre-fueling technology is adopted to effectively protect the kinematic pair and prolong the service life of the engine.
The high-quality alloy cast iron cylinder block with an arc-reinforcing rib grid structure, high-strength vermicular cast iron cylinder head, double-safety anti-impact cylinder gasket structure, and original cooling technology at the bottom of the cylinder head are applied, with high reliability.
The electronically-control fuel injection system is adopted, with stable operation, good transient speed regulation, and strong loading capacity.
Four-valve and turbocharged & intercooled technologies, ensuring sufficient air intake, sufficient combustion, and low fuel consumption. Yuchai's patented carbon scraping and self-cleaning technology ensures low lubricating oil consumption.
| Model | YCC401020-G31 (YC6C1020-D31) |
YCC401070-G31 (YC6C1070-D31) |
YCC401220-G31 (YC6C1220-D31) |
YCC401320-G31 (YC6C1320-D31) |
YCC401520-G31 (YC6C1520-D31) |
YCC401660-G31 (YC6C1660-D31) |
YCC401660-G30 (YC6C1660-D30) |
|
| Cylinder quantity - bore/stroke (mm) | 6-200×210 | 6-200×210 | 6-200×210 | 6-200×210 | 6-200×210 | 6-200×210 | 6-200×210 | |
| Displacement (L) | 39.58 | 39.58 | 39.58 | 39.58 | 39.58 | 39.58 | 39.58 | |
| Number of valves per cylinder | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
| Aspiration | TAA | TAA | TAA | TAA | TAA | TAA | TAA | |
| PRP/Speed(kW/rpm) | 680/1500 | 715/1500 | 815/1500 | 880/1500 | 1016/1500 | 1110/1500 | 1110/1500 | |
| ESP/Speed(kW/rpm) | 748/1500 | 787/1500 | 897/1500 | 968/1500 | 1118/1500 | 1221/1500 | 1221/1500 | |
| COP/Speed(kW/rpm) | / | / | / | / | / | / | / | |
| DCP/Speed(kW/rpm) | 680/1500 | 715/1500 | 815/1500 | 880/1500 | 1016/1500 | / | 1110/1500 | |
| Fuel System | EUP | EUP | EUP | EUP | EUP | EUP | HPCR | |
| Generator | PRP(kWe) | 600 | 650 | 730 | 800 | 900 | 1000 | 1000 |
| ESP(kWe) | 660 | 710 | 800 | 900 | 1000 | 1100 | 1100 | |
| COP(kWe) | / | / | / | / | / | / | / | |
| DCP(kWe) | 600 | 650 | 730 | 800 | 900 | / | 1000 | |
Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
One head for one cylinder, with a maintenance window on the side of the engine body, which is convenient for maintenance. Support dual-energy startup.
Electric pre-fueling technology is adopted to effectively protect the kinematic pair and prolong the service life of the engine.
The high-quality alloy cast iron cylinder block with an arc-reinforcing rib grid structure, high-strength vermicular cast iron cylinder head, double-safety anti-impact cylinder gasket structure, and original cooling technology at the bottom of the cylinder head are applied, with high reliability.
The electronically-control fuel injection system is adopted, with stable operation, good transient speed regulation, and strong loading capacity.
Four-valve and turbocharged & intercooled technologies, ensuring sufficient air intake, sufficient combustion, and low fuel consumption. Yuchai's patented carbon scraping and self-cleaning technology ensures low lubricating oil consumption.
