Power range：279kW~478kW
Applications： inland or offshore fishing boats and cargo ships
The application of the four-valve technology effectively reduces the intake and exhaust noise of the engine; The rear gear chamber and advanced point-line meshing gear technology reduce the mechanical noise of the powertrain.
The application of the four-valve technology ensures substantially increased flow area of intake and exhaust, and the central fuel injector enables more uniform atomization and more complete combustion; P pump and P nozzle ensure higher injection pressure and stronger working capacity, more reasonable matching between the fuel injector and combustion chamber, uniform mixing, and best fuel atomization quality, and enable a more than 15% reduction in the mechanical loss and less pumping loss, as well as a 10-15% reduction in fuel consumption compared with engines at the same power level.
Yuchai YC6T product, following the demanding specifications for mechanical development verification, has been subject to a cumulative durability bench test of 20,000 hours. The structure of one head for one cylinder ensures easy maintenance. The cylinder head bolts are evenly distributed and stressed. The valve system, high camshaft arrangement, short and thick push rod, and roller tappet make the product highly reliable. The advanced equipment and quality control from casting to assembly ensure higher quality.
|
Item |
YC6T Series marine diesel engine |
||||
|
Model |
YC6T650L-C28 |
YC6T540L-C28 |
YC6T480L-C28 |
YC6T450L-C28 |
YC6T380L-C28 |
|
Number of cylinders - bore × stroke (mm) |
6-145×165 |
6-145×165 |
|||
|
Displacement (L) |
16.35 |
16.35 |
|||
|
Number of valves per cylinder |
4 |
4 |
|||
|
Induction system |
Turbocharged & intercooled |
Turbocharged & intercooled |
|||
|
Rated power/speed (kW(Ps)/r/min) |
478(650)/1800 |
396(540)/1800 |
352(480)/1800 |
330(450)/1500 |
279(380)/1200 |
|
Overload power/speed (kW(Ps)/r/min) |
526(715)/1858 |
435.6(595)/1858 |
387.2(530)/1858 |
363(495)/1548 |
306.9(420)/1239 |
|
Min. specific fuel consumption of external characteristics (g/kW·h) |
≤205 |
≤205 |
|||
|
Certificates |
ZC、CCS、EIAPP、China II |
ZC、CCS、EIAPP、China II |
|||
|
Diemension (L×W×H) (mm) |
1971×1124×1624 |
1971×1124×1624 |
|||
|
Dry weight (kg) |
1980 |
1980 |
|||
Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
The application of the four-valve technology effectively reduces the intake and exhaust noise of the engine; The rear gear chamber and advanced point-line meshing gear technology reduce the mechanical noise of the powertrain.
The application of the four-valve technology ensures substantially increased flow area of intake and exhaust, and the central fuel injector enables more uniform atomization and more complete combustion; P pump and P nozzle ensure higher injection pressure and stronger working capacity, more reasonable matching between the fuel injector and combustion chamber, uniform mixing, and best fuel atomization quality, and enable a more than 15% reduction in the mechanical loss and less pumping loss, as well as a 10-15% reduction in fuel consumption compared with engines at the same power level.
Yuchai YC6T product, following the demanding specifications for mechanical development verification, has been subject to a cumulative durability bench test of 20,000 hours. The structure of one head for one cylinder ensures easy maintenance. The cylinder head bolts are evenly distributed and stressed. The valve system, high camshaft arrangement, short and thick push rod, and roller tappet make the product highly reliable. The advanced equipment and quality control from casting to assembly ensure higher quality.
