Power range：219kW~293.7kW
Applications：public service ships, yachts and speedboats of 7~20m
The reduction soft mesh starter ensures smooth starting; the damping gear enables noise to be shielded; the oil pan of the cast aluminum marine engine reduces vibration noise.
The parts are developed based on the 6L platform and are 94% used universally for 6L series vehicle diesel engines, with good maintainability.
The HPCR system enables strong power and quick response. The four-valve, efficient turbocharged & intercooled technologies, Yuchai's combustion, NVH development + electronically-control fuel injection technologies ensure low comprehensive fuel consumption (with the minimum fuel consumption of 190.15g/kw.h), low operating cost, subdivided purposes, road spectrum collection, fine calibration based on different purposes, guaranteed fuel saving, light dead weight (5% lighter than competing products), and more fuel-efficient.
Developed based on Yuchai's 6L vehicle engine platform with 300,000 6L vehicle engines in the market, the product is mature and stable; the engine block and cylinder head are made of alloy cast iron, with high strength; the 42CrMo forged steel crankshaft enables the product small in size, light in weight and compact in outline structure; the statistical service life of B10 is up to 13,000 hours.
|
Model |
YC6L365L-C20 |
YC6L320L-C20 |
YC6L300L-C20 |
YC6L280-C20 |
YC6L270L-C20 |
YC6L230L-C20 |
|
Cylinder quantity - bore/stroke(mm) |
6-113×140 |
|||||
|
Displacement(L) |
8.42 |
|||||
|
Number of valves per cylinder |
4 |
|||||
|
Induction system |
Turbocharged & intercooled |
|||||
|
Rated power/speed(kW（Ps）/r/min) |
267（365）/2200 |
235（320）/2200 |
219（300）/2200 |
206/（280）2100 |
198（270）/2100 |
169（230）/2300 |
|
Overload power/speed(kW（Ps）/r/min) |
293.7（400）/2266 |
258.5（350）/2266 |
240.9（330）/2266 |
227（310）/2168 |
218（295）/2168 |
186（255）/2374 |
|
Min. specific fuel consumption of external characteristics (g/kW·h) |
≤205 |
|||||
|
Diemension（Length × width × height）（mm） |
1466×966×997 |
|||||
|
Certificates |
CCS、EIAPP、China II |
ZC、CCS、EIAPP、China II |
ZC、CCS、EIAPP、China II |
|||
|
Dry weight（kg） |
900 |
|||||
Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
The reduction soft mesh starter ensures smooth starting; the damping gear enables noise to be shielded; the oil pan of the cast aluminum marine engine reduces vibration noise.
The parts are developed based on the 6L platform and are 94% used universally for 6L series vehicle diesel engines, with good maintainability.
The HPCR system enables strong power and quick response. The four-valve, efficient turbocharged & intercooled technologies, Yuchai's combustion, NVH development + electronically-control fuel injection technologies ensure low comprehensive fuel consumption (with the minimum fuel consumption of 190.15g/kw.h), low operating cost, subdivided purposes, road spectrum collection, fine calibration based on different purposes, guaranteed fuel saving, light dead weight (5% lighter than competing products), and more fuel-efficient.
Developed based on Yuchai's 6L vehicle engine platform with 300,000 6L vehicle engines in the market, the product is mature and stable; the engine block and cylinder head are made of alloy cast iron, with high strength; the 42CrMo forged steel crankshaft enables the product small in size, light in weight and compact in outline structure; the statistical service life of B10 is up to 13,000 hours.
