Passed the road adaptability test of about 3 million km (including high-temperature test, alpine-cold test and plateau test)
Passed the reliability bench test of about 10,000 hours
High-altitude adaptability: no power loss at altitudes less than 2,000 m, suitable for applications at altitudes of 4,800m
Cold starting performance: smooth starting at an ambient temperature of -35°C
Application of an advanced high pressure common rail (HPCR) fuel system and Yuchai's patented in-cylinder combustion technology, effectively improving the engine power and torque, and maximizing the load-carrying capacity of vehicles
Application of Yuchai's patented efficient combustion technology, achieving a minimum fuel consumption of 194 g/kwh
Road spectrum collection and fine calibration according to market segment and applications, ensuring fuel economy
Use of an intelligent fuel-saving switch: The position switch is adjusted according to the real-time load, allowing the vehicle to operate in the economical range all the time, thus reducing the fuel consumption by at least 10%
Lighter dead weight (5% lighter than competitors) and more fuel-efficient
Use of a Bosch common rail system, achieving multiple injections and accurate control, and reducing combustion noise
Reduction soft meshing starter, ensuring smooth start
Damping silicone oil damper
Application of a grooved cylinder head cover and a noise-reduction cylinder head cover gasket, effectively reducing noise transmission
More sufficient combustion, reducing pollution of oil by carbon and other harmful gases
Optimized piston material and lubricating oil passage, avoiding any impact of ultra-high temperature on the service life of lubricating oil
Use of an oil filter, achieving higher filtration efficiency and dust holding capacity, lower flow resistance, and stronger breakage resistance of filter paper
|
Platform |
Product Series |
Model Series |
Displacement (L) |
Bore × Stroke |
Number of Valves per Cylinder |
Emissions |
Power |
Torque |
Fuel System |
Exhaust Aftertreatment |
Dry Weight (kg) |
Change Cycle |
B10 Service Life (10,000 km) |
|
YC6J |
6J-30 |
YC6J180-30 |
6.494 |
105×125 |
4 |
Euro III |
132/2500 |
650/1200~1700 |
BOSCH high pressure common rail system |
No |
670 |
20,000 (standard) |
70 |
|
YC6J190-30 |
140/2500 |
700/1200~1700 |
|||||||||||
|
YC6J200-30 |
147/2500 |
730/1200~1700 |
|||||||||||
|
YC6J220-30 |
162/2500 |
800/1200~1700 |
|||||||||||
|
YC6J230-30 |
170/2500 |
850/1200~1700 |
|||||||||||
|
6J-33 |
YC6J160-33 |
2 |
Euro II |
118/2500 |
550/1400~1700 |
In-line mechanical pump |
No |
||||||
|
YC6J170-33 |
125/2500 |
550/1400~1700 |
|||||||||||
|
YC6J180-33 |
132/2500 |
590/1400~1700 |
|||||||||||
|
YC6J190-33 |
140/2500 |
630/1400~1700 |
|||||||||||
|
YC6J200-33 |
147/2500 |
700/1400~1700 |
|||||||||||
|
YC6J210-33 |
155/2500 |
710/1400~1700 |
|||||||||||
|
YC6J220-33 |
162/2500 |
760/1400~1700 |
|||||||||||
|
6J-52 |
YC6J180-52 |
4 |
Euro Ⅴ |
132/2300 |
700/1200~1800 |
BOSCH high pressure common rail system |
SCR |
||||||
|
YC6J200-52 |
147/2300 |
800/1200~1800 |
|||||||||||
|
YC6J220-52 |
162/2300 |
860/1200~1800 |
|||||||||||
|
YC6J245-52 |
180/2300 |
950/1200~1800 |
Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
Passed the road adaptability test of about 3 million km (including high-temperature test, alpine-cold test and plateau test)
Passed the reliability bench test of about 10,000 hours
High-altitude adaptability: no power loss at altitudes less than 2,000 m, suitable for applications at altitudes of 4,800m
Cold starting performance: smooth starting at an ambient temperature of -35°C
Application of an advanced high pressure common rail (HPCR) fuel system and Yuchai's patented in-cylinder combustion technology, effectively improving the engine power and torque, and maximizing the load-carrying capacity of vehicles
Application of Yuchai's patented efficient combustion technology, achieving a minimum fuel consumption of 194 g/kwh
Road spectrum collection and fine calibration according to market segment and applications, ensuring fuel economy
Use of an intelligent fuel-saving switch: The position switch is adjusted according to the real-time load, allowing the vehicle to operate in the economical range all the time, thus reducing the fuel consumption by at least 10%
Lighter dead weight (5% lighter than competitors) and more fuel-efficient
Use of a Bosch common rail system, achieving multiple injections and accurate control, and reducing combustion noise
Reduction soft meshing starter, ensuring smooth start
Damping silicone oil damper
Application of a grooved cylinder head cover and a noise-reduction cylinder head cover gasket, effectively reducing noise transmission
More sufficient combustion, reducing pollution of oil by carbon and other harmful gases
Optimized piston material and lubricating oil passage, avoiding any impact of ultra-high temperature on the service life of lubricating oil
Use of an oil filter, achieving higher filtration efficiency and dust holding capacity, lower flow resistance, and stronger breakage resistance of filter paper
