Products
1. Reliability
Passed the road adaptability test of about 2.6 million km (including high-temperature test, alpine-cold test and plateau test) and the reliability bench test of about 30,000 hours
Additional stiffening ribs arranged outside the engine block and a cambered structure of the skirt, ensuring higher strength of the engine block and meeting the requirements of high blasting pressure
Use of a crankshaft made of 42CrMo forged steel, ensuring high strength and toughness, and strong explosion pressure resistance; optimized internal oil passage, improving the lubrication effect and achieving reliable power output
2. Fuel economy
Application of a mature four-valve structure and Yuchai's patented combustion technology, achieving a minimum fuel consumption of 198 g/kWh
Road spectrum collection and fine calibration according to market segment and applications, ensuring fuel economy
Use of an intelligent fuel-saving switch: The position switch is adjusted according to the real-time load, allowing the vehicle to operate in the economical range all the time, thus reducing the fuel consumption by at least 10%
3. Safety
Maximum speed control — be able to protect the engine from any damage due to excessive mechanical stress or thermal load
Limp home — be able to reduce the power in case of a fault in the electronic control system, ensuring that the vehicle can be driven to the maintenance station nearby
Low oil pressure protection — real-time monitoring and automatic fault diagnosis, achieving higher driving safety
Thermal protection — automatic torque limiting and overheating protection
4. Comfort
Use of a noise reduction gear chamber with internal stiffeners, a noise-reduction cast aluminum cylinder head cover, and a noise-reduction oil pan
Application of pilot injection control, intelligent idle speed control and other electronic control technologies, effectively reducing engine vibration and noise
|
Product Series |
Model Series |
Displacement (L) |
Bore × Stroke |
Number of Valves per Cylinder |
Emissions |
Power (kw/rpm) |
Torque (N.m/rpm) |
Fuel System |
Exhaust Aftertreatment |
Dry Weight (kg) |
Oil Change Cycle |
B10 Service Life (10,000 km) |
|
YC4EG-50 |
YC4EG160-50 |
4.73 |
112X120 |
4 |
Euro Ⅴ |
118/2500 |
600/1300~1600 |
BOSCH high pressure common rail system |
SCR |
470 |
20,000 (standard)
|
60 |
|
YC4EG170-50 |
125/2500 |
600/1300~1600 |
||||||||||
|
YC4EG185-50 |
136/2500 |
700/1300~1500 |
||||||||||
|
YC4EG200-50 |
147/2500 |
735/1300~1500 |
||||||||||
|
YC4EG220-50 |
160/2500 |
810/1300~1700 |
Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
1. Reliability
Passed the road adaptability test of about 2.6 million km (including high-temperature test, alpine-cold test and plateau test) and the reliability bench test of about 30,000 hours
Additional stiffening ribs arranged outside the engine block and a cambered structure of the skirt, ensuring higher strength of the engine block and meeting the requirements of high blasting pressure
Use of a crankshaft made of 42CrMo forged steel, ensuring high strength and toughness, and strong explosion pressure resistance; optimized internal oil passage, improving the lubrication effect and achieving reliable power output
2. Fuel economy
Application of a mature four-valve structure and Yuchai's patented combustion technology, achieving a minimum fuel consumption of 198 g/kWh
Road spectrum collection and fine calibration according to market segment and applications, ensuring fuel economy
Use of an intelligent fuel-saving switch: The position switch is adjusted according to the real-time load, allowing the vehicle to operate in the economical range all the time, thus reducing the fuel consumption by at least 10%
3. Safety
Maximum speed control — be able to protect the engine from any damage due to excessive mechanical stress or thermal load
Limp home — be able to reduce the power in case of a fault in the electronic control system, ensuring that the vehicle can be driven to the maintenance station nearby
Low oil pressure protection — real-time monitoring and automatic fault diagnosis, achieving higher driving safety
Thermal protection — automatic torque limiting and overheating protection
4. Comfort
Use of a noise reduction gear chamber with internal stiffeners, a noise-reduction cast aluminum cylinder head cover, and a noise-reduction oil pan
Application of pilot injection control, intelligent idle speed control and other electronic control technologies, effectively reducing engine vibration and noise
