Power range：65kW~139.7kW
Applications：fishing boats, tourist ships of 10~20m, 55~75kW boat gensets, etc.
The water-cooled exhaust pipe + wet post-turbo pipe + efficient cooling heat exchanger and intercooler ensure good heat dissipation performance; the efficient combustion technology enables low fuel consumption and leading NVH performance in China.
Wide power range and high torque reserve.
Highly strengthened engine, with an overhaul period of over 10,000 hours.
Advanced high pressure common rail technology of Bosch enables accurate control and low fuel consumption.
|
Model |
YC4D190L-C20 |
YC4D125L-C22 |
YC4D105L-C22 |
YC4D90L-C22 |
|
Number of cylinders - bore × stroke (mm) |
4-108×115 |
|||
|
Displacement (L) |
4.214 |
|||
|
Number of valves per cylinder |
2 |
|||
|
Induction system |
Turbocharged |
|||
|
Rated power/speed (kW(Ps)/r/min) |
127（170）/3000 |
90（125）/1500 |
74（105）/1500 |
65（90）/1500 |
|
Overload power/speed (kW(Ps)/r/min) |
139.7（190）/3096 |
99(140)/1500 |
81.4（115）/1500 |
71.5（100）/1500 |
|
Min. specific fuel consumption(g/kW·h) |
≤220 |
|||
|
Certificates |
CCS、China II |
|||
|
Dimension (L×W×H) (mm) |
1123×740×854 |
|||
|
Dry weight (kg) |
490 |
|||
Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibration
Damping gear
The water-cooled exhaust pipe + wet post-turbo pipe + efficient cooling heat exchanger and intercooler ensure good heat dissipation performance; the efficient combustion technology enables low fuel consumption and leading NVH performance in China.
Wide power range and high torque reserve.
Highly strengthened engine, with an overhaul period of over 10,000 hours.
Advanced high pressure common rail technology of Bosch enables accurate control and low fuel consumption.
